OVERVIEW
ITD industrial open frame touchscreen panel PCs is a cost-effective and budget-priced all in one industrial computers series that provide reliability, durability, and industrial OEMs with vast selection of technologies and solutions simplify PLC, HMI, and SCADA applications. The rugged all steel enclosures and highly-durable glass front surface provide the durability needed for demanding industrial environments. ITD open frame touchscreen panel PCs cater to those who seek to further customize the appearance of their application and come with industrial/commercial-grade LCD flat screen sizes, touchscreen interface, Intel's comprehensive embedded processors and chipsets, low power consumption, fanless design, and scratch-resistant capabilities which are ideal for process manufacturing, discrete manufacturing, industrial automation, process control, building automation, access control, room reservation, room scheduling, and custom HMI applications.
Open Frame Flush Mount PCAP Touch Panel PC | |||
| Model Name | ITD101PPCT5Y** | ||
| IP Rating | IP65 Front | ||
PC Systems Options | |||
| ARM Based RK3288(RK3566/RK3399 optional) | X86 Windows Based | X86 Windows Based | |
| CPU: Quad-Core Cortex-A17 1.8GHz | CPU: Intel? Celeron J1900 | CPU: Intel Core i3/i5/i7 | |
| Chipset: RK3288/RK3566/RK3399 | Chipset: Intel? NM10 Express | Chipset: Intel? HD Graphics, Support 1080p | |
| Memory: 2G, max. 4G | Memory: 4GB(Max. 8GB) | Memory: 4GB(Max. 16GB/32GB) | |
| HDD/SSD: 8G, max. 64G | Storage: 1 x SATA, 1 x mSATA, Default to 64GB SSD | HDD/SSD: 1 x SATA, 1 x mSATA, Default to 64GB SSD | |
| 1×HDMI | 1×VGA, 1×HDMI | 1×VGA, 1×HDMI | |
| 1×USB 2.0 | 3×USB 2.0, 1×USB3.0 | 2×USB 2.0, 2×USB3.0 | |
| 1×mini-SD slot | 1×COM(RS232/422/485) | 1×COM(RS232/422/485) | |
| 1×LAN | 1×LAN(Dual LAN optional) | 1×LAN | |
| 1×Audio Out | 1×Audio Out, 1×MIC In | 1×Audio Out, 1×MIC In | |
| WFI, Bluetooth included | Expansion: USB, COM, Mini-PCIe | Expansion: USB, COM, Mini-PCIe | |
LCD Panel | |||
| Screen Diagonal (Inch/cm) | 10.1” | ||
| Display Active Screen Size (mm) | 216.96(H)×135.6(V) | ||
| Aspect Ratio | 16:10 | ||
| Physical Resolution | 1280×800 | ||
| Maximum Resolution Supported | 1920×1200 | ||
| Colors | 262K | ||
| Brightness (cd/m2) | 350 (1000 cd/m2 optional) | ||
| Contrast Ratio | 800:1 | ||
| View Angels | 85/85/85/85 | ||
| Backlight/Backlight Lifetime | LED Backlight with 50000Hours'Lifetime | ||
Touch Panel | |||
| Touch Options | Projected Capacitive Touch Screen | ||
| Touch Drivers | Plug and Play | ||
Operation | |||
| Operating Temperature Range | -10~60°C (-20~70°C Optional) | ||
| Humidity Range (RH) | 10-90% | ||
| 24/7/365 Use | Supported | ||
Power | |||
| Power Indicator | Green LED | ||
| Power Input | DC 12V (DC24V, DC9-36V, AC100-240V input optional) | ||
| Power Consumption | 20W | ||
Order Information | |||
| 10.1”Open Frame Flush Mount Panel PC with PCAP Touch, J1900 | ITD101PPCT5YJ1 | ||
| 10.1”Open Frame Flush Mount Panel PC with Tempered Glass, J1900 | ITD101PPCG1YJ1 | ||
| 10.1”Open Frame Flush Mount Panel PC with PCAP Touch, i3 | ITD101PPCT5YI3 | ||
| 10.1”Open Frame Flush Mount Panel PC with Tempered Glass, i3 | ITD101PPCT5YI3 | ||
| 10.1”Open Frame Flush Mount Panel PC with PCAP Touch, i5 | ITD101PPCT5YI5 | ||
| 10.1”Open Frame Flush Mount Panel PC with Tempered Glass, i5 | ITD101PPCT5YI5 | ||
| 10.1”Open Frame Flush Mount Panel PC with PCAP Touch, i7 | ITD101PPCT5YI7 | ||
| 10.1”Open Frame Flush Mount Panel PC with Tempered Glass, i7 | ITD101PPCT5YI7 | ||
