Products > Sunlight Readable LCD > High Bright Sunlight Readable Panel PC Chassis Closed Frame  >  15.6 inch Chassis High Bright Sunlight Readable Panel PC
15.6 inch Chassis High Bright Sunlight Readable Panel PC
BENEFITES
- Exceptional quality and highly engineered sunlight readable industrial panel computer
- High Performance Processor, Graphics, Memory and Power
- All steel construction designed for harsh & industrial environments
- Easy-to-install VESA(75/100mm) wall mounting
- Optional touchscreens like resistive, IR, SAW, PCAP
- High brightness from 1000nits to 1500nits optional
- Long lasting product cycle for continuity thru all phases of project
OVERVIEW
ITD industrial chassis sunlight readable panel PCs is a cost-effective and budget-priced all in one industrial computers series that provide reliability, durability, and industrial OEMs with vast selection of technologies and solutions simplify PLC, HMI, and SCADA applications. The rugged all steel enclosures and highly-durable glass (anti-reflective, anti-glare optional) front surface provide the durability needed for demanding industrial environments. Optical bonding done optional between TFT panel and tempered glass/touch panel is available for better visualization in sunlight. ITD high brightness chassis panel PCs come with high brightness LCD flat screen sizes, touchscreen interface, Intel's comprehensive embedded processors and chipsets, low power consumption, and scratch-resistant capabilities which are ideal for process manufacturing, discrete manufacturing, industrial automation, process control, building automation, access control, room reservation, room scheduling, and custom HMI for indoor, semi-outdoor or outdoor applications.




Chassis High Brightness Panel PC

Model Name

ITD156PPCG1HBL**

IP Rating

IP65 Front Panel Optional


PC Systems Options

ARM Android Based RK3288(RK3368 optional)

X86 Windows Based

X86 Windows Based

CPU: Quad-Core Cortex-A17 1.8GHz

CPU: Intel Celeron J1900

CPU: Intel Core i3/i5/i7

Chipset: N/A

Chipset: Intel NM10 Express

Chipset: Intel HD Graphics, Support 1080p

Memory: 1G/2G

Memory: 2GB(Max. 8GB)

Memory: 2GB(Max. 8GB)

HDD/SSD: 8G

HDD/SSD:500G/64G

HDD/SSD:500G/64G

1¡ÁHDMI

1¡ÁVGA, 1¡ÁHDMI

1¡ÁVGA, 1¡ÁHDMI

1¡ÁUSB 2.0

2¡ÁUSB 2.0, 2¡ÁUSB3.0

2¡ÁUSB 2.0, 2¡ÁUSB3.0

1¡Ámini-SD slot

1¡ÁCOM(RS232/422/485)

1¡ÁCOM(RS232/422/485)

1¡ÁLAN

1¡ÁLAN

1¡ÁLAN

1¡ÁAudio Out

1¡ÁAudio Out, 1¡ÁMIC In

1¡ÁAudio Out, 1¡ÁMIC In

Expansion: SSD

Expansion: USB, COM, Mini-PCIe

Expansion: USB, COM, Mini-PCIe


LCD Panel

Screen Diagonal (Inch)

15.6¡±

Display Active Screen Size (cm)

344.232(H)¡Á193.536(V)

Aspect Ratio

16:9

Physical Resolution

1366¡Á768

Maximum Resolution Supported

1920¡Á1080

Colors

16.7M

Brightness (cd/m2)

1000(1500 Optional)

Contrast Ratio

500:1

View Angels

45/45/30/20

Backlight/Backlight Lifetime

LED Backlight with 50000 Hours¡¯ Lifetime


Touch Panel

Touch Options

Resistive, IR, PCAP, SAW,

Touch Drivers

Windows, Linux, Android, Mac, Raspberry Pi


Operation

Operating Temperature Range

-10~60¡ãC (-20~70¡ãC Optional)

Humidity Range (RH)

10-90%

24/7/365 Use

Supported


Power

Power Indicator

Green LED

Power Input

DC 12V

Power Consumption

21W


Order Information

15.6¡±1000nits Chassis Panel PC with Resistive Touch, J1900

ITD156PPCT1HBLJ1

15.6¡±1000nits Chassis Panel PC with PCAP Touch, J1900

ITD156PPCT5HBLJ1

15.6¡±1000nits Chassis Panel PC with IR Touch, J1900

ITD156PPCT2HBLJ1

15.6¡±1000nits Chassis Panel PC with Tempered Glass, J1900

ITD156PPCG1HBLJ1

15.6¡±1000nits Chassis Panel PC with Resistive Touch, i5

ITD156PPCT1HBLI5

15.6¡±1000nits Chassis Panel PC with PCAP Touch, i5

ITD156PPCT5HBLI5

15.6¡±1000nits Chassis Panel PC with IR Touch, i5

ITD156PPCT2HBLJ1

15.6¡±1000nits Chassis Panel PC with Tempered Glass, i5

ITD156PPCG1HBLI5
