Products > Industrial Touchscreen LCD > Rugged Full IP65 IP66 Touch Screen Monitor  >  19 inch Full IP65/IP66 Touchscreen LCD Monitor
19 inch Full IP65/IP66 Touchscreen LCD Monitor
BENEFITES
-Exceptional quality and highly engineered industrial heavy duty monitors
-Optional touchscreens like resistive and PCAP
-Ruggedized levels of NEMA 12, 4X, 4, IP52, IP56, IP65 ratings from all directions
-Solid steel and stainless steel or aluminum alloy enclosures
-IP65 sealed, Full IP65 I/O connectors protect from any particles, water, and corrosive agents
-Accuracy in high-use applications
-Long lasting product cycle for continuity thru all phases of project
OVERVIEW
ITDfull IP65 LCD touchscreen displays are fully-integrated units that combine touch screen, waterproof and dustproof, fully sealed stainless steel chassis or aluminum alloy chassis and I/O with IP65/ NEMA 4 Ingress protection rating designed to be tough and rugged. The enclosure features easy-to clean stainless steel/aluminum alloy construction that is corrosion resistant.They are built for demanding applications with high industrial requirement, such as food processing, beverage, pharmaceutical and tobacco industries for operator control and monitoring. ITD full-range selection is provided in screen sizes from 7¡±~21.5¡±.




Full IP65/IP66
Touchscreen Monitor

Model Name

ITD19CMG1IP*1

IP Rating

Full IP65/IP66(IP67 optional)


LCD Panel

Screen Diagonal (Inch/cm)

19¡±

Display Active Screen Size (mm)

376.3(H) x 301.1(V)mm

Aspect Ratio

4:3

Physical Resolution

1280x1024

Maximum Resolution Supported

1920x1080

Colors

16.7M

Brightness (cd/m2)

250nits

Contrast Ratio

1000:1

View Angels

85/85/80/80

Backlight/Backlight Lifetime

LED Backlight with 50000 Hours¡¯Lifetime


Touch Panel



Touch Options

Resistive, PCAP

Touch Drivers

Windows, Linux, Android, Mac, Raspberry Pi


Input / Output



Video Input

1 ¡Á VGA

N/A

1 ¡Á HDMI(Optional)

Audio

N/A

Touch Connector

1 ¡Á USB(Optional)

Power Connector

1 ¡Á DC2.0


Operation

Operating Temperature Range

-10~60¡ãC (-20~70¡ãCOptional)

Humidity Range (RH)

10-90%

24/7/365 Use

Supported


Power



Power Indicator

N/A

Power Input

DC 12V

Power Consumption

30W


Order Information



19¡±Full IP65/IP66 LCD Monitor with Resistive Touch, Aluminum Housing

ITD19CMT1IPA1

19¡±Full IP65/IP66 LCD Monitor with PCAP Touch, Aluminum Housing

ITD19CMT5IPA1

19¡±Full IP65/IP66 LCD Monitor with Resistive Touch, Stainless Steel Housing

ITD19CMT1IPS1

19¡±Full IP65/IP66 LCD Monitor with PCAP Touch, Stainless Steel Housing

ITD19CMT5IPS1

19¡±Full IP65/IP66 LCD Monitor with Tempered Glass, Aluminum Housing

ITD19CMG1IPA1

19¡±Full IP65/IP66 LCD Monitor with Tempered Glass, Stainless Steel Housing

ITD19CMG1IPS1

Next£º21.5 inch Full IP65/IP66 Touchscreen LCD Monitor
Previous£º17 inch Full IP65/IP66 Touchscreen LCD Monitor
