BENEFITES
- High-brightness display up to 5000 nits for perfect visibility in daylight.
- Full IP65 protection ensures weatherproof performance in rain, dust, and humidity.
- Optical bonding enhances clarity, reduces reflection, and strengthens the screen.
- Ultra-slim housing with a clean, modern appearance for seamless wall mounting.
- Auto brightness adjustment optimizes energy use and screen visibility 24/7.
- Industrial-grade panel supports wide temperature operation without blackening.
- Optional PCAP touch provides smooth interaction even in harsh environments.
- Maintenance-free design lowers long-term operating costs.
- Ready for digital signage integration in smart cities, retail, and transport sectors.

OVERVIEW
ITD’s 49” Ultra-Thin Wall-Mount Outdoor Display is designed to deliver high-impact digital signage in outdoor environments where visibility, aesthetics, and reliability are essential. With a generous 49-inch screen size, it is ideal for commercial displays, outdoor advertising, and public information boards that demand attention from a distance. The full IP65-rated enclosure, optical bonding, and anti-reflective high-brightness panel ensure unmatched outdoor performance, while the streamlined, maintenance-free structure makes it a cost-effective solution for long-term deployment in any weather.

IP65 Full Outdoor Digital Screen TV
Model Name		ITD49CMODIPWxx
IP Rating		IP65
Single Media Player/Monitor Option
Video Formats Supported: MP4, AVI, DAT, MPG, RM, RMVB, AVC, FLV Audio Formats Supported: MP3, WMA, OGG, AAC, AC, DTS, FLAC, APE Picture Formats Supported: JPEG, BMP, GIF, PNG File Formats Supported: FAT, FAT32, NTFS		1 ×HDMI Input 2 ×USB 2.0, 1 ×TF Card Slot
PC Systems Options
ARM Based RK3568(RK3288/RK3576/RK3588/RK3399 optional)	X86 Based		X86 Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel? Celeron J1900/J4125/J6412		CPU: Intel Core i3/i5/i7 (4th/5th/6th/7th/8th/10th/11th 12th, 13th Gen. optional)
Chipset: Rockchip	Chipset: Intel? SOC		Chipset: Intel? SOC
Memory: 2G, max. 8G	Memory: 4GB(Max. 16GB)		Memory: 4GB(Max. 64GB)
Storage: 16G, max. 256G	Storage: 1×MSATA, 1×SATA, 1×M.2(available for J4125/J6412)		Storage: 1×MSATA, 1×SATA, 1×M.2
1×HDMI Output	1×HDMI Output(optional)		1×HDMI Output(optional)
1×USB 2.0	2×USB		2×USB
1×mini-SD slot(optional)	2×COM(RS232/422/485) (optional)		2×COM(RS232/422/485) (optional)
1×LAN	1×LAN		1×LAN
1×Audio Out(optional)	1×Audio Out, 1×MIC In(optional)		1×Audio Out, 1×MIC In(optional)
Expansion: USB, COM port	Expansion: USB, COM		Expansion: USB, COM
Android, Linux Supported	Windows 7/10/11/Embedded/IoT, Linux Supported		Windows 7/10/11/Embedded/IoT, Linux Supported
LCD Panel
Screen Diagonal (Inch)		49”
Display Active Screen Size (mm)		1073.78(W)×604(H)
Pixel Pitch(mm)		0.27963×0.27963
Aspect Ratio		16:9
Physical Resolution		1920×1080 (3840×2160 optional)
Response Time		6ms
Colors		1.07B
Brightness (cd/m2)		1500 cd/m2(2000~4000cd/m2 optional)
Contrast Ratio		1100:1
View Angels		89/89/89/89
Backlight/Backlight Lifetime		LED Backlight with 50000Hours'Lifetime
Touch Panel Available for Network Version
Touch Options		PCAP Touch
Touch Drivers		Plug and Play
Operation
Operating Temperature Range		-30~50°C
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Structure
Housing Material		Galvanized Steel Sheet with Outdoor Anti-rust Painting
Surface Coating		Anti-Reflective/Anti-UV Coating
Mounting		Wall Mounting
Power /Speakers
Power Indicator		Green LED
Power Input		Internal Power Supply, AC 100V~240V
Power Consumption Speakers		150W 2×8W
Order Information
49”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with HDMI input		ITD49CMODIPWxx01
49”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Android Player		ITD49CMODIPWxxEx
49”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Windows Player		ITD49CMODIPWxxJx
