BENEFITES
- Max.5000 nits ultra-bright panel guarantees vibrant content even under strong sunlight.
- Optical bonding improves touch response, durability, and sunlight readability.
- Fully IP65-rated enclosure protects against water, dust, and outdoor elements.
- Equipped with waterproof cooling fans for efficient heat dissipation in hot climates.
- Filter-free and maintenance-free design reduces long-term operating costs.
- Ambient light sensor ensures auto-brightness adjustment for day and night use.
- Wide temperature tolerance supports performance in both cold and hot weather.
- QWP technology allows clear viewing even with polarized sunglasses.
- Ultra-thin form factor enables clean, flush wall-mounted installations.
- Ideal for large-format digital signage in outdoor commercial and public spaces.

OVERVIEW
ITD’s 55” Ultra-Thin Landscape Wall-Mount Outdoor Display is a premium-grade solution built for large-format outdoor digital signage, offering a striking balance of performance, design, and durability. Tailored for retail storefronts, transportation terminals, and digital billboards, this display combines 5000 nits brightness, optical bonding, and a sleek, ultra-thin chassis to deliver vivid, uninterrupted messaging in any environment. Its robust IP65-rated construction and waterproof fans design enable 24/7 maintenance-free operation, even in extreme outdoor conditions.

IP65 Full Outdoor Screen LCD Display
Model Name		ITD55CMODIPWxx
IP Rating		IP65
Single Media Player/Monitor Option
Video Formats Supported: MP4, AVI, DAT, MPG, RM, RMVB, AVC, FLV Audio Formats Supported: MP3, WMA, OGG, AAC, AC, DTS, FLAC, APE Picture Formats Supported: JPEG, BMP, GIF, PNG File Formats Supported: FAT, FAT32, NTFS		1 ×HDMI Input 2 ×USB 2.0, 1 ×TF Card Slot
PC Systems Options
ARM Based RK3568(RK3288/RK3576/RK3588/RK3399 optional)	X86 Based		X86 Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel? Celeron J1900/J4125/J6412		CPU: Intel Core i3/i5/i7 (4th/5th/6th/7th/8th/10th/11th 12th, 13th Gen. optional)
Chipset: Rockchip	Chipset: Intel? SOC		Chipset: Intel? SOC
Memory: 2G, max. 8G	Memory: 4GB(Max. 16GB)		Memory: 4GB(Max. 64GB)
Storage: 16G, max. 256G	Storage: 1×MSATA, 1×SATA, 1×M.2(available for J4125/J6412)		Storage: 1×MSATA, 1×SATA, 1×M.2
1×HDMI Output	1×HDMI Output(optional)		1×HDMI Output(optional)
1×USB 2.0	2×USB		2×USB
1×mini-SD slot(optional)	2×COM(RS232/422/485) (optional)		2×COM(RS232/422/485) (optional)
1×LAN	1×LAN		1×LAN
1×Audio Out(optional)	1×Audio Out, 1×MIC In(optional)		1×Audio Out, 1×MIC In(optional)
Expansion: USB, COM port	Expansion: USB, COM		Expansion: USB, COM
Android, Linux Supported	Windows 7/10/11/Embedded/IoT, Linux Supported		Windows 7/10/11/Embedded/IoT, Linux Supported
LCD Panel
Screen Diagonal (Inch)		55”
Display Active Screen Size (mm)		1209.6(W)×680.4(H)
Pixel Pitch(mm)		0.315×0.315
Aspect Ratio		16:9
Physical Resolution		1920×1080 (3840×2160 optional)
Response Time		8ms
Colors		1.07B
Brightness (cd/m2)		1500 cd/m2(2000~5000cd/m2 optional)
Contrast Ratio		1200:1
View Angels		89/89/89/89
Backlight/Backlight Lifetime		LED Backlight with 50000Hours'Lifetime
Touch Panel Available for Network Version
Touch Options		PCAP Touch
Touch Drivers		Plug and Play
Operation
Operating Temperature Range		-30~50°C
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Structure
Housing Material		Galvanized Steel Sheet with Outdoor Anti-rust Painting
Surface Coating		Anti-Reflective/Anti-UV Coating
Mounting		Wall Mounting
Power /Speakers
Power Indicator		Green LED
Power Input		Internal Power Supply, AC 100V~240V
Power Consumption Speakers		220W 2×10W
Order Information
55”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with HDMI input		ITD55CMODIPWxx01
55”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Android Player		ITD55CMODIPWxxEx
55”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Windows Player		ITD55CMODIPWxxJx
