BENEFITES
- Max. 5000 nits ultra-bright panel guarantees vibrant content even under strong sunlight.
- Optical bonding improves touch response, durability, and sunlight readability.
- Fully IP65-rated enclosure protects against water, dust, and outdoor elements.
- Equipped with waterproof cooling fans for efficient heat dissipation in hot climates.
- Filter-free and maintenance-free design reduces long-term operating costs.
- Ambient light sensor ensures auto-brightness adjustment for day and night use.
- Wide temperature tolerance supports performance in both cold and hot weather.
- QWP technology allows clear viewing even with polarized sunglasses.
- Ultra-thin form factor enables clean, flush wall-mounted installations.
- Ideal for large-format digital signage in outdoor commercial and public spaces.

OVERVIEW
ITD’s 65” Ultra-Thin Landscape Wall-Mount Outdoor Display is purpose-built for large-scale outdoor digital signage, offering unmatched visual impact and performance in high-traffic environments. Perfect for outdoor advertising, stadiums, transit stations, and corporate campuses, this display features 5000 nits sunlight-readable brightness, a fully sealed IP65 structure, and waterproof active cooling fans to ensure reliable operation under all weather conditions. Despite its size, the display maintains a slim profile, delivering both aesthetics and functionality in one powerful solution.

IP65 Full Outdoor All Weatherproof Digital Screen
Model Name		ITD65CMODIPWxx
IP Rating		IP65
Single Media Player/Monitor Option
Video Formats Supported: MP4, AVI, DAT, MPG, RM, RMVB, AVC, FLV Audio Formats Supported: MP3, WMA, OGG, AAC, AC, DTS, FLAC, APE Picture Formats Supported: JPEG, BMP, GIF, PNG File Formats Supported: FAT, FAT32, NTFS		1 ×HDMI Input 2 ×USB 2.0, 1 ×TF Card Slot
PC Systems Options
ARM Based RK3568(RK3288/RK3576/RK3588/RK3399 optional)	X86 Based		X86 Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel? Celeron J1900/J4125/J6412		CPU: Intel Core i3/i5/i7 (4th/5th/6th/7th/8th/10th/11th 12th, 13th Gen. optional)
Chipset: Rockchip	Chipset: Intel? SOC		Chipset: Intel? SOC
Memory: 2G, max. 8G	Memory: 4GB(Max. 16GB)		Memory: 4GB(Max. 64GB)
Storage: 16G, max. 256G	Storage: 1×MSATA, 1×SATA, 1×M.2(available for J4125/J6412)		Storage: 1×MSATA, 1×SATA, 1×M.2
1×HDMI Output	1×HDMI Output(optional)		1×HDMI Output(optional)
1×USB 2.0	2×USB		2×USB
1×mini-SD slot(optional)	2×COM(RS232/422/485) (optional)		2×COM(RS232/422/485) (optional)
1×LAN	1×LAN		1×LAN
1×Audio Out(optional)	1×Audio Out, 1×MIC In(optional)		1×Audio Out, 1×MIC In(optional)
Expansion: USB, COM port	Expansion: USB, COM		Expansion: USB, COM
Android, Linux Supported	Windows 7/10/11/Embedded/IoT, Linux Supported		Windows 7/10/11/Embedded/IoT, Linux Supported
LCD Panel
Screen Diagonal (Inch)		65”
Display Active Screen Size (mm)		1428.48(W)×803.52(H)
Pixel Pitch(mm)		0.372×0.372
Aspect Ratio		16:9
Physical Resolution		3840×2160 optional
Response Time		8ms
Colors		1.07B
Brightness (cd/m2)		2500 cd/m2(1000~5000cd/m2 optional)
Contrast Ratio		1200:1
View Angels		89/89/89/89
Backlight/Backlight Lifetime		LED Backlight with 50000Hours'Lifetime
Touch Panel Available for Network Version
Touch Options		PCAP Touch
Touch Drivers		Plug and Play
Operation
Operating Temperature Range		-30~50°C
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Structure
Housing Material		Galvanized Steel Sheet with Outdoor Anti-rust Painting
Surface Coating		Anti-Reflective/Anti-UV Coating
Mounting		Wall Mounting
Power /Speakers
Power Indicator		Green LED
Power Input		Internal Power Supply, AC 100V~240V
Power Consumption Speakers		300W 2×10W
Order Information
65”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with HDMI input		ITD65CMODIPWxx01
65”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Android Player		ITD65CMODIPWxxEx
65”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Windows Player		ITD65CMODIPWxxJx
