BENEFITES
- Extra-large 75” screen provides impactful messaging and visibility in open spaces.
- 5000 nits ultra-bright backlight ensures clear viewing even in direct sunlight.
- Optical bonding improves durability and reduces glare for better outdoor clarity.
- Full IP65-rated construction offers all-weather protection against dust and water.
- Integrated waterproof cooling fans support stable thermal management in high-heat environments.
- Filter-free and maintenance-free structure ensures long-term reliability with zero routine service.
- Automatic brightness adjustment adapts to ambient light to balance visibility and power efficiency.
- Polarized sunglasses-compatible display allows effortless viewing in any light condition.
- Flexible input interface options for easy integration with digital signage systems or media players.
- Perfect for large-scale public information displays, transit signage, and outdoor control panels.

OVERVIEW
ITD’s 75” Ultra-Thin Landscape Wall-Mount Outdoor Display is a professional-grade, large-format display tailored for outdoor environments that demand maximum visibility, reliable uptime, and strong public engagement. Ideal for transportation hubs, outdoor command centers, large-scale digital wayfinding, and commercial media walls, this display offers exceptional readability from long viewing distances, combined with a sealed IP65 design and active waterproof cooling. Despite its size, the display remains easy to integrate, with a clean, ultra-thin profile and robust structural design for long-term outdoor use.

IP65 Full Outdoor Digital Signage Display
Model Name		ITD75CMODIPWxx
IP Rating		IP65
Single Media Player/Monitor Option
Video Formats Supported: MP4, AVI, DAT, MPG, RM, RMVB, AVC, FLV Audio Formats Supported: MP3, WMA, OGG, AAC, AC, DTS, FLAC, APE Picture Formats Supported: JPEG, BMP, GIF, PNG File Formats Supported: FAT, FAT32, NTFS		1 ×HDMI Input 2 ×USB 2.0, 1 ×TF Card Slot
PC Systems Options
ARM Based RK3568(RK3288/RK3576/RK3588/RK3399 optional)	X86 Based		X86 Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel? Celeron J1900/J4125/J6412		CPU: Intel Core i3/i5/i7 (4th/5th/6th/7th/8th/10th/11th 12th, 13th Gen. optional)
Chipset: Rockchip	Chipset: Intel? SOC		Chipset: Intel? SOC
Memory: 2G, max. 8G	Memory: 4GB(Max. 16GB)		Memory: 4GB(Max. 64GB)
Storage: 16G, max. 256G	Storage: 1×MSATA, 1×SATA, 1×M.2(available for J4125/J6412)		Storage: 1×MSATA, 1×SATA, 1×M.2
1×HDMI Output	1×HDMI Output(optional)		1×HDMI Output(optional)
1×USB 2.0	2×USB		2×USB
1×mini-SD slot(optional)	2×COM(RS232/422/485) (optional)		2×COM(RS232/422/485) (optional)
1×LAN	1×LAN		1×LAN
1×Audio Out(optional)	1×Audio Out, 1×MIC In(optional)		1×Audio Out, 1×MIC In(optional)
Expansion: USB, COM port	Expansion: USB, COM		Expansion: USB, COM
Android, Linux Supported	Windows 7/10/11/Embedded/IoT, Linux Supported		Windows 7/10/11/Embedded/IoT, Linux Supported
LCD Panel
Screen Diagonal (Inch)		75”
Display Active Screen Size (mm)		1649.66(W)×927.936(H)
Pixel Pitch(mm)		0.4296×0.4296
Aspect Ratio		16:9
Physical Resolution		3840×2160 optional
Response Time		8ms
Colors		1.07B
Brightness (cd/m2)		2500 cd/m2(1000~5000cd/m2 optional)
Contrast Ratio		1200:1
View Angels		89/89/89/89
Backlight/Backlight Lifetime		LED Backlight with 50000Hours'Lifetime
Touch Panel Available for Network Version
Touch Options		PCAP Touch
Touch Drivers		Plug and Play
Operation
Operating Temperature Range		-30~50°C
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Structure
Housing Material		Galvanized Steel Sheet with Outdoor Anti-rust Painting
Surface Coating		Anti-Reflective/Anti-UV Coating
Mounting		Wall Mounting
Power /Speakers
Power Indicator		Green LED
Power Input		Internal Power Supply, AC 100V~240V
Power Consumption Speakers		450W 2×10W
Order Information
75”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with HDMI input		ITD75CMODIPWxx01
75”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Android Player		ITD75CMODIPWxxEx
75”IP65 Full Outdoor Ultra-Slim Wall-Mounted LCD Display with Windows Player		ITD75CMODIPWxxJx
