产品特性：
◆整合显示器/Touchpad鼠标/88带数字区键盘
◆卓越的视频效果，支持不同分辨率
◆支持完整的DDC2B功能，未切换计算机也能侦测屏幕型号
◆双界面PS/2&USB键盘鼠标切换器连接控制电脑
◆桌面式安装设计
◆人性化设计，一人可安装与拆卸，提高管理员工作效率
◆支持各种工控机、服务器设备
◆兼容支持 Microsoft、Linux、Unix等系列操作系统
Specification
|
LCD Panel |
|
Model Name |
ITD17KMT101 |
|
Screen Size (diagonal) |
17" |
|
Display Resolution (pixels) |
1280x1024 |
|
Active Display Area (mm) |
337.92 (H) x 270.34 (V) |
|
Pixel Pitch(mm) |
0.264 |
|
Brightness (cd/m  2) |
250 (typ.) |
|
Contrast Ratio |
1000:1 (typ.) |
|
Viewing Angles |
85/85/80/80 |
|
Backlight Lifetime |
50000h |
|
Computer Connections |
|
Type |
Direct 1, Max:4 Direct 4, Max:128 Direct 8, Max: 256 Direct 16, Max: 512 |
|
Cable Port |
D-SUB15 (LCD, PS11/USB keyboard, mouse),OSD switch Support |
|
Switch |
|
Switch Mode |
Hot Key, OSD Menu |
|
Switch Scan Time |
1-255 second(OSD adjustable) |
|
Keyboard/Mouse |
104 Mechanical Mute Keyboard Touchpad |
|
Power |
|
Power Source |
AC 100~240 V,Universal,  10% 47-63Hz |
|
Power Consumption |
 35W |
|
Mechanical |
|
Material |
High-Strength and Anti- Corrosive Steel Plate |
|
Color |
Insulated black paint (other colors optional) |
|
Certifications |
|
Compliance |
Meet CE,ROHS,FCC,CCC |
|
Order Information |
|
ITD17KMT101 |
17"TFT LCD/Keyboard/Touchpad/100~240V AC Power/2 Port Switch |
|
ITD17KMT104 |
17"TFT LCD/Keyboard/Touchpad/100~240V AC Power/4 Port Switch |
|
ITD17KMT108 |
17"TFT LCD/Keyboard/Touchpad/100~240V AC Power/8 Port Switch |
|
ITD17KMT116 |
17"TFT LCD/Keyboard/Touchpad/100~240V AC Power/16 Port Switch | |
