特点：
易于使用安装，即插即用
提供类似于iPad的纯平面外观设计，强大的防水能力，提高了可靠性和寿命
卓越10点触摸体验和独一无二的触摸信号穿透性能，带或不带手套均能使用
安装简便，支持VESA标准壁挂支架或者四周固定孔位
支持Windows? XP/7/8，Android，Linux Ubuntu等多种操作系统
改良功率，超低功耗
兼具模拟及数字视频信号输入接口
Specification
|
LCD Panel |
|
Model Name |
ITD19OFT5P01 |
|
Screen Size (diagonal) |
19" |
|
Display Resolution (pixels) |
1280x1024 |
|
Active Display Area (mm) |
376.32 (H) x 301.06 (V) |
|
Pixel Pitch(mm) |
0.294 |
|
Brightness (cd/m 2) |
250 (typ.) |
|
Contrast Ratio |
1000:1 (typ.) |
|
Viewing Angles |
85/85/80/80 |
|
Backlight Lifetime |
50000 |
|
Touch Screen |
|
Type |
Projected Capacitive Touch Screen |
|
Touch Connectors |
USB or RS232 |
|
Interface |
|
Signal Connector |
VGA, DVI, HDMI |
|
Optional Interface |
AV, S-Video, BNC, RS232, HD-SDI |
|
Power |
|
Power Source |
DC 2.0 12V AC 100~240 V,Universal, 10% |
|
Power Consumption |
 32W
|
|
Mechanical |
|
Material |
Steel housing |
|
Mounting |
Mounting brackets around, VESA |
|
Certifications |
|
Compliance |
Meet CE,ROHS,FCC,CCC |
|
Order Information |
|
ITD19OFT5P01 |
19"open frame monitor with Pcap touch 2points |
|
ITD19OFT5P02 |
19"open frame monitor with Pcap touch 10points | |
