产品型号
产品尺寸17"
产品描述

Features:

Bezel-Free, true flat surface, iPad-look style
High contrast color TFT LCD display supports resolution up to 1280 x 1024
Supports DDC 1/2B for Plug & Play compatibility
Advanced OSD control for picture quality adjustment and sound
Rugged aluminum front bezel and steel housing fully enclosed chassis, IP65 front

Specification

LCD Panel

Model Name

ITD17DMT3Q1

Screen Size (diagonal)

17"

Display Resolution (pixels)

1280x1024

Active Display Area (mm)

337.92(H) x 270.34 (V)

Pixel Pitch(mm)

0.264

Brightness (cd/m2)

250 (typ.)

Contrast Ratio

1000:1 (typ.)

Viewing Angles

8585/80/80

Backlight Lifetime

50000

Touch Screen

Type

Surface Acoustic Wave

Touch Connectors

USB and RS232

Interface

Signal Connector

VGA/DVI

Power

Power Source

DC 2.0 12V  AC 100~240 V, Universal,10%

Power Consumption

25W

Mechanical

Material

Strong metal housing and brushed aluminum bezel

Mounting

VESA rugged stand

Certifications

Compliance

Meet CE,ROHS,FCC,CCC, UL, CB, TCO

Optional

Built-in PC

Yes
