特点：
强固型不锈钢或铝合金外壳，整机达到NEMA 4 IP65防水级别
支持DDC 1/2B 即插即用
黑色沙纹喷粉或拉丝工艺,高强度防止磨损和腐蚀,能在恶劣环境中使用，稳定性好
采用工业五线电阻触摸屏其特点耐高温、高湿,精确度高,灵敏度高。
Specification
|
LCD Panel |
|
Model Name |
ITD15CMT1IP01 |
|
Screen Size (diagonal) |
15" |
|
Display Resolution (pixels) |
1024x768 |
|
Active Display Area (mm) |
304.1 (H) x 228.1 (V) |
|
Pixel Pitch(mm) |
0.297 |
|
Brightness (cd/m 2) |
250 (typ.) |
|
Contrast Ratio |
500:1 (typ.) |
|
Viewing Angles |
80/80/70/60 |
|
Backlight Lifetime |
50000h |
|
Touch Screen |
|
Type |
5 wires-Resistive |
|
Touch Connectors |
USB or RS232 |
|
Interface |
|
Signal Connector |
VGA or HDMI |
|
Optional Interface |
AV |
|
Power |
|
Power Source |
DC 12V AC 100~240 V,Universal,  10% |
|
Power Consumption |
 25W |
|
Mechanical |
|
Material |
Fully Aluminum Enclosed |
|
Mounting |
VESA |
|
Certifications |
|
Compliance |
Meet CE,ROHS,FCC,CCC |
|
Order Information |
|
ITD15CMT2IP01 |
15" Fully IP65/IP66 chassis monitor with IR touch |
|
ITD15CMT5IP01 |
15" Fully IP65/IP66 chassis monitor with PCAP touch |
|
ITD15CMT1HBIP01 |
15" Fully IP65/IP66 high rightness 1000nits chassis monitor with 5 wires-resistive touch |
|
ITD15CMT5HBIP01 |
15" Fully IP65/IP66 high rightness 1000nits chassis monitor with PCAP touch | |
