15 inch Rear Mount SAW Touch Monitor
BENEFITES
-All steel/aluminum construction provides rugged frame for public use environments
-Special“FLANGE” design around easy-to-install to make total true flat front surface
-Ten independent touch points, plug and play
-Eliminates dust and debris build-up at the edge and corners of the display
-Provides improved power efficiency and reduced consumption
-Responds to a light touch in activating response
-Easy-to-clean surface without bezels
-Long lasting product cycle for continuity thru all phases of project
OVERVIEW
ITD’s flush mount projected capacitive touch displays are engineered specifically for industrial customers who are looking for a rugged and durable touch screen without having to sacrifice on image quality. Featuring a special “FLANGE” around withzero bezel design, the touchscreen monitor can easily be wiped clean, thereby eliminating having to worry about dust and dirt collection, and easily make a true flat front surface of console, which helps extend the use of your display. ITD industrial multi touch displays are accurate, responsive and easy-to-use, enabling migration of existing single touch applications to a gesture-based interface that creates and delivers popular user interactions such as pan, zoom and rotate, which ideal for kiosks, gaming, banking and all kinds of self-service terminals.
|
Rear MountSAW Touchscreen Monitor
|
|
Model Name |
ITD15OFT3E1 |
|
IP Rating |
IP65 Front Panel |
|
LCD Panel
|
|
Screen Diagonal (Inch) |
15” |
|
Display Active Screen Size (cm) |
304.13(H)×228.1(V) |
|
Aspect Ratio |
4:3 |
|
Physical Resolution |
1024×768 |
|
Maximum Resolution Supported |
1920×1080 |
|
Colors |
16.2M |
|
Brightness (cd/m2) |
250 |
|
Contrast Ratio |
700:1 |
|
View Angels |
80/80/60/80 |
|
Backlight/Backlight Lifetime |
LED Backlight with 50000Hours’Lifetime |
|
Touch Panel
|
|
Touch Technology |
SurfaceAcoustic Wave Touch |
|
Touch Drivers |
Windows, Linux, Android |
|
Touch Life |
50,000,000times/click |
|
Surface Hardness |
7H |
|
Input / Output
|
|
Video Input |
1 × VGA |
|
1 × DVI-I |
|
1 × HDMI |
|
Audio |
1 × PC-Audio |
|
Touch Connector |
1 × USB |
|
Power Connector |
1 × DC2.0 |
|
Operation
|
|
Operating Temperature Range |
-10~60°C (-20~70°COptional) |
|
Humidity Range (RH) |
10-90% |
|
24/7/365 Use |
Supported |
|
Power
|
|
Power Indicator |
Green LED |
|
Power Input |
DC 12V |
|
Power Consumption |
20W |
|
Optional
|
|
Side Mounting Brackets |
