OVERVIEW
ITD industrial panel mount fanless panel PCs provide reliability, durability, and industrial OEMs with vast selection of technologies and solutions simplify PLC, HMI, and SCADA applications. The rugged all die-casing aluminum enclosures with robust aluminum alloy front bezel with thickness of 3mm, 6mm, 10mm optional and highly-durable glass front surface provide the durability needed for demanding industrial environments. The flat industrial panel mount fanless panel PC is combined with PCAP or resistive touch makes true flat surface with easy to clean. Industrial panel mount fanless panel PCs come with industrial-grade LCD flat screen sizes, touchscreen interface, Intel's comprehensive embedded processors and chipsets, low power consumption, and scratch-resistant capabilities are ideal for process manufacturing, discrete manufacturing, industrial automation, process control, robots, building automation, access control, room reservation, room scheduling, and custom HMI applications.

Flat Bezel Industrial Panel PC
Model Name		ITD24PPCT5X** V2
IP Rating		IP65 Front Panel
PC Systems Options
ARM Android Based RK3288(RK3399 optional)	X86 Based		X86 Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel Celeron J1900/J4125/6412		CPU: Intel Core i3/i5/i7 4th~11th Generation
Chipset: Rockchip	Chipset: Intel Bay Trail SOC		Chipset: Intel SoC
	Graphic: Intel HD Graphics (By CPU)		Chipset: Intel HD Graphics (By CPU)
Memory: 2G Max. 8GB	Memory: 4GB, Max. 8GB/16GB; DDR4 SODIMM x1		Memory: 4GB, Max. 32GB; DDR4 SODIMM x2
HDD/SSD: 8G Max. 64GB	Storage: 1 x SATA, 1 x mSATA, Default to 64GB SSD		Storage: 1 x SATA, 1 x mSATA, Default to 64GB SSD
1×HDMI Output	1×VGA, 1×HDMI		1×VGA, 1×HDMI
1×USB 2.0	2×USB 2.0, 2×USB3.0		2×USB 2.0, 2×USB3.0
1×TF Slot	2×COM(RS232/422/485)		1×COM(RS232/422/485)
1×LAN	1×LAN (Dual LAN optional)		1×LAN (Dual LAN optional)
1×Audio Output	1×Audio Out, 1×MIC In		1×Audio Out, 1×MIC In
1×COM	Expansion: USB, COM, Mini-PCIe, etc.		Expansion: USB, COM, Mini-PCIe, etc.
OS Support: Android 7.1/8/9/10/11	OS Support: Windows 7/10/11, Linux		OS Support: Windows 7/10/11, Linux
LCD Panel
Screen Diagonal (Inch)		23.8”
Display Active Screen Size (cm)		531.36(H) x 298.89(V)mm
Aspect Ratio		16:9
Physical Resolution		1920 x 1080
Maximum Resolution Supported		1920 x 1080
Colors		16.7M
Brightness (cd/m2)		250cd/m2 (1000cd/m2,1500cd/m2optional)
Contrast Ratio		1000:1
View Angels		89/89/89/89
Backlight/Backlight Lifetime		LED Backlight with 50000Hours'Lifetime
Touch Panel
Touch Options		PCAP
Touch Drivers		Windows, Linux, Android, Mac, Raspberry Pi; Plug and Play for PCAP
Operation
Operating Temperature Range		-10~60°C
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Power
Power Indicator		Green LED
Power Input		DC 12V (DC 24V, DC9-36V input optional)
Power Consumption		40W
Order Information
23.8” Panel Mount Panel PC with Resistive Touch, J1900		ITD24PPCT1XJ1 V2
23.8” Panel Mount Panel PC with PCAP Touch, J1900		ITD24PPCT5XJ1 V2
23.8” Panel Mount Panel PC with Tempered Glass, J1900		ITD24PPCG1XJ1 V2
23.8” Panel Mount Panel PC with Resistive Touch, J4125		ITD24PPCT1XJ2 V2
23.8” Panel Mount Panel PC with PCAP Touch, J4125		ITD24PPCT5XJ2 V2
23.8” Panel Mount Panel PC with Tempered Glass, J4125		ITD24PPCG1XJ2 V2
23.8” Panel Mount Panel PC with Resistive Touch, J6412		ITD24PPCT1XJ3 V2
23.8” Panel Mount Panel PC with PCAP Touch, J6412		ITD24PPCT5XJ3 V2
23.8” Panel Mount Panel PC with Tempered Glass, J6412		ITD24PPCG1XJ3 V2
23.8” Panel Mount Panel PC with Resistive Touch, i3		ITD24PPCT1XI3 V2
23.8” Panel Mount Panel PC with PCAP Touch, i3		ITD24PPCT5XI3 V2
23.8” Panel Mount Panel PC with Tempered Glass, i3		ITD24PPCG1XI3 V2
23.8” Panel Mount Panel PC with Resistive Touch, i5		ITD24PPCT1XI5 V2
23.8” Panel Mount Panel PC with PCAP Touch, i5		ITD24PPCT5XI5 V2
23.8” Panel Mount Panel PC with Tempered Glass, i5		ITD24PPCG1XI5 V2
23.8” Panel Mount Panel PC with Resistive Touch, i7		ITD24PPCT1XI7 V2
23.8” Panel Mount Panel PC with PCAP Touch, i7		ITD24PPCT5XI7 V2
23.8” Panel Mount Panel PC with Tempered Glass, i7		ITD24PPCG1XI7 V2
