OVERVIEW
ITD wall mounted digital signage displays series is a truly dynamic medium that puts on a show, engages with impact and communicates and conveys all manner of media in unique, branded and tailored style across display screens that project in ways that conventional media messaging just can¡¯t touch. Content is customized with text, graphics and video that shouts, schmoozes or just speaks spectacularly. ITD wall-mounted digital signage displays incorporate media playing with optional single SD card and USB port, ARM based player and x86 based player integrated, a sleek design and commercial functionality into an affordable digital signage solution. Featuring an elegant design with zero-bezel and ultra-slim profile, the ITD wall-mounted digital signage series is the ideal display solution for digital signage applications in retail stores, restaurants, medical offices, healthcare, corporate meeting areas, education, hotel and leisure environments..
|
| |||
|
Model Name |
ITD101ADG1** | ||
|
IP Rating |
IP65 Front Panel Optional | ||
|
| |||
|
1 ¡ÁUSB 2.0, 1¡ÁSD Card Slot, 1¡ÁHDMI Input(Optional) Video Formats Supported: MP4, AVI, DAT, MPG, RM, RMVB, AVC, FLV Audio Formats Supported: MP3, WMA, OGG, AAC, AC, DTS, FLAC, APE Picture Formats Supported: JPEG, BMP, GIF, PNG File Formats Supported: FAT, FAT32, NTFS | |||
|
| |||
|
ARM Android Based RK3288(RK3368 optional) |
X86 Windows Based |
X86 Windows Based | |
|
CPU: Quad-Core Cortex-A17 1.8GHz |
CPU: Intel Celeron J1900 |
CPU: Intel Core i3/i5/i7 | |
|
Chipset: N/A |
Chipset: Intel NM10 Express |
Chipset: Intel HD Graphics, Support 1080p | |
|
Memory: 1G/2G |
Memory: 2GB(Max. 8GB) |
Memory: 2GB(Max. 8GB) | |
|
HDD/SSD: 8G |
HDD/SSD:500G/64G |
HDD/SSD:500G/64G | |
|
1¡ÁHDMI |
1¡ÁVGA, 1¡ÁHDMI |
1¡ÁVGA, 1¡ÁHDMI | |
|
1¡ÁUSB 2.0 |
2¡ÁUSB 2.0, 2¡ÁUSB3.0 |
2¡ÁUSB 2.0, 2¡ÁUSB3.0 | |
|
1¡Ámini-SD slot |
1¡ÁCOM(RS232/422/485) |
1¡ÁCOM(RS232/422/485) | |
|
1¡ÁLAN |
1¡ÁLAN |
1¡ÁLAN | |
|
1¡ÁAudio Out |
1¡ÁAudio Out, 1¡ÁMIC In |
1¡ÁAudio Out, 1¡ÁMIC In | |
|
Expansion: SSD |
Expansion: USB, COM, Mini-PCIe |
Expansion: USB, COM, Mini-PCIe | |
|
| |||
|
Screen Diagonal (Inch) |
10.1¡± | ||
|
Display Active Screen Size (cm) |
216.96(H)¡Á135.6(V) | ||
|
Aspect Ratio |
16:10 | ||
|
Physical Resolution |
1280¡Á800 | ||
|
Maximum Resolution Supported |
1920¡Á1080 | ||
|
Colors |
262K | ||
|
Brightness (cd/m2) |
350 | ||
|
Contrast Ratio |
500:1 | ||
|
View Angels |
85/85/85/85 | ||
|
Backlight/Backlight Lifetime |
LED Backlight with 50000Hours' Lifetime | ||
|
| |||
|
Touch Options |
IR, PCAP, Touch Foil | ||
|
Touch Drivers |
Windows, Linux, Android, Mac, Raspberry Pi | ||
|
| |||
|
Operating Temperature Range |
0~50¡ãC (-10~60¡ãC Optional) | ||
|
Humidity Range (RH) |
10-90% | ||
|
24/7/365 Use |
Supported | ||
|
| |||
|
Power Indicator |
Green LED | ||
|
Power Input |
DC 12V | ||
|
Power Consumption Speakers |
8.25W 2¡Á5W | ||
|
| |||
|
10.1¡±Wall Mounted Single Digital Signage |
ITD101ADG1A1 | ||
|
10.1¡±Wall Mounted Android Network Digital Signage |
ITD101ADG1BE1 | ||
|
10.1¡±Wall Mounted Windows(J1900) Network Digital Signage |
ITD101ADG1BJ1 | ||
|
10.1¡±Wall Mounted Windows(Intel i3) Network Digital Signage |
ITD101ADG1BC1 | ||
