BENEFITES
- Built to withstand harsh industrial environments, including exposure to high-pressure, high-temperature water jets, dust, and other contaminants. This durability ensures longevity and reliable operation even in challenging conditions.
- The smooth, stainless steel construction combined with the flat touchscreen interface allows for easy cleaning and disinfection, which is essential in industries where hygiene is critical.
- IP69K rating ensures that the monitors can withstand high-pressure cleaning with hot water and cleaning agents without damage.
- Designed and tested to meet industry standards and regulations for safety, hygiene, and performance, ensuring that they meet the requirements of specific applications and industries.
- M12 Waterproof I/O connectors protected from any particles, water, and corrosive agents.
- Long lasting product cycle for continuity thru all phases of project
IP69K Touchscreen Monitor | |
| Model Name | ITD10CMx1IPS1-69K |
| IP Rating | IP69K |
LCD Panel | |
| Screen Diagonal (Inch/cm) | 10.4¡± |
| Aspect Ratio | 4 : 3 |
| Display Active Screen Size (mm) | 211.2(H)¡Á158.4(V)mm |
| Physical Resolution | 1024¡Á768 |
| Pixel Pitch | 0.20625¡Á0.20625 |
| Response Time | 16ms |
| Colors | 262K/16.7M |
| Brightness (cd/m2) | 350nits (1000nits optional) |
| Contrast Ratio | 900:1 |
| View Angels | 75/75/75/75 |
| Backlight/Backlight Lifetime | LED Backlight with 30000 Hours¡¯ Lifetime |
Touch Pane | |
| Touch Options | Resistive, PCAP |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
Default Waterproof Input / Output | |
| HDMI Output | 1 ¡Á HDMI input |
| Touch Port | 1 ¡Á USB |
| Power Port | 1 ¡Á DC2.0 |
Operatio | |
| Operating Temperature Range | -10~60¡ãC (-20~70¡ãC Optional) |
| Humidity Range (RH) | 10-90% Non-Condensing |
| 24/7/365 Use | Supported |
Power | |
| Power Indicator | N/A |
| Power Input | DC 12V (DC9~36V input optional) |
| Power Consumption | 8W |
Order Information | |
| 10.4¡±IP69K Stainless Steel LCD Monitor with Resistive Touch | ITD10CMT1IPS1-69K |
| 10.4¡±IP69K Stainless Steel LCD Monitor with PCAP Touch | ITD10CMT5IPS1-69K |
| 10.4¡±IP69K Stainless Steel LCD Monitor with Tempered Glass No Touch | ITD10CMG1IPS1-69K |
| 10.4¡±IP69K Stainless Steel LCD Monitor with Resistive Touch, 1000nits | ITD10CMT1HBIPS2-69K |
| 10.4¡±IP69K Stainless Steel LCD Monitor with PCAP Touch. 1000nits | ITD10CMT5HBIPS2-69K |
| 10.4¡±IP69K Stainless Steel LCD Monitor with Tempered Glass No Touch, 1000nits | ITD10CMG1HBIPS2-69K |
