OVERVIEW
ITD industrial open frame touchscreen panel PCs is a cost-effective and budget-priced all in one industrial computers series that provide reliability, durability, and industrial OEMs with vast selection of technologies and solutions simplify PLC, HMI, and SCADA applications. The rugged all steel enclosures and highly-durable glass front surface provide the durability needed for demanding industrial environments. ITD open frame touchscreen panel PCs cater to those who seek to further customize the appearance of their application and come with industrial/commercial-grade LCD flat screen sizes, touchscreen interface, Intel's comprehensive embedded processors and chipsets, low power consumption, fanless design, and scratch-resistant capabilities which are ideal for process manufacturing, discrete manufacturing, industrial automation, process control, building automation, access control, room reservation, room scheduling, and custom HMI applications.

Open Frame Flush Mount PCAP Touch Panel PC
Model Name		ITD10PPCT5Y**
IP Rating		IP65 Front
PC Systems Options
ARM Based RK3288(RK3566/RK3399 optional)	X86 Windows Based		X86 Windows Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel? Celeron J1900		CPU: Intel Core i3/i5/i7
Chipset: RK3288/RK3566/RK3399	Chipset: Intel? NM10 Express		Chipset: Intel? HD Graphics, Support 1080p
Memory: 2G, max. 4G	Memory: 4GB(Max. 8GB)		Memory: 4GB(Max. 16GB/32GB)
HDD/SSD: 8G, max. 64G	Storage: 1 x SATA, 1 x mSATA, Default to 64GB SSD		HDD/SSD: 1 x SATA, 1 x mSATA, Default to 64GB SSD
1×HDMI	1×VGA, 1×HDMI		1×VGA, 1×HDMI
1×USB 2.0	3×USB 2.0, 1×USB3.0		2×USB 2.0, 2×USB3.0
1×mini-SD slot	1×COM(RS232/422/485)		1×COM(RS232/422/485)
1×LAN	1×LAN(Dual LAN optional)		1×LAN
1×Audio Out	1×Audio Out, 1×MIC In		1×Audio Out, 1×MIC In
WFI, Bluetooth included	Expansion: USB, COM, Mini-PCIe		Expansion: USB, COM, Mini-PCIe
LCD Panel
Screen Diagonal (Inch/cm)		10.4”
Display Active Screen Size (mm)		211.2(H) x 158.4(V)mm
Aspect Ratio		4:3
Physical Resolution		1024 x 768
Maximum Resolution Supported		1920 x 1080
Colors		16.2M
Brightness (cd/m2)		350 (1000 cd/m2 optional)
Contrast Ratio		800:1
View Angels		80/80/80/80
Backlight/Backlight Lifetime		LED Backlight with 50000Hours'Lifetime
Touch Panel
Touch Options		Projected Capacitive Touch Screen
Touch Drivers		Plug and Play
Operation
Operating Temperature Range		-10~60°C (-20~70°C Optional)
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Power
Power Indicator		Green LED
Power Input		DC 12V (DC24V, DC9-36V, AC100-240V input optional)
Power Consumption		20W
Order Information
10.4”Open Frame Flush Mount Panel PC with PCAP Touch, J1900		ITD10PPCT5YJ1
10.4”Open Frame Flush Mount Panel PC with Tempered Glass, J1900		ITD10PPCG1YJ1
10.4”Open Frame Flush Mount Panel PC with PCAP Touch, i3		ITD10PPCT5YI3
10.4”Open Frame Flush Mount Panel PC with Tempered Glass, i3		ITD10PPCT5YI3
10.4”Open Frame Flush Mount Panel PC with PCAP Touch, i5		ITD10PPCT5YI5
10.4”Open Frame Flush Mount Panel PC with Tempered Glass, i5		ITD10PPCT5YI5
10.4”Open Frame Flush Mount Panel PC with PCAP Touch, i7		ITD10PPCT5YI7
10.4”Open Frame Flush Mount Panel PC with Tempered Glass, i7		ITD10PPCT5YI7
