BENEFITES
- Exceptional quality and highly engineered industrial monitors
- Optional touchscreens like resistive, IR, SAW, PCAP
- All steel construction designed for harsh and industrial environments
- Easy-to-install cabinet and chassis VESA-mount display
- Accuracy in high-use applications
- Long lasting product cycle for continuity thru all phases of project
OVERVIEW
ITD industrial chassis LCD displays provide reliability, durability, and expected longer product life. The rugged all steel enclosures and highly-durable glass front surface provide the durability needed for demanding industrial environments. Industrial chassis LCD monitors are designed for system integrators, digital signage, kiosks, POI, OEM machinery, transportation depots, theme and amusement parks, airports, industrial/factory automation, railroad terminals and industrial machinery builder applications. ITD full-range selection is provided in screen sizes from 5.7”~85”.
|
| |
|
Model Name |
ITD11CMN101 |
|
IP Rating |
N/A |
|
| |
|
Screen Diagonal (Inch) |
11.6” |
|
Display Active Screen Size (mm) |
256.32(H) x 144.18(V) |
|
Aspect Ratio |
16:10 |
|
Physical Resolution |
1920×1080 |
|
Maximum Resolution Supported |
1920:1080 |
|
Colors |
262K |
|
Brightness (cd/m2) |
350nits |
|
Contrast Ratio |
800:1 |
|
View Angels |
89/89/89/89 |
|
Backlight/Backlight Lifetime |
LED Backlight with 50000 Hours’ Lifetime |
|
| |
|
Touch Options |
Resistive, IR, PCAP, SAW |
|
Touch Drivers |
Windows, Linux, Android, Mac, Raspberry Pi |
|
| |
|
Video Input |
1 × VGA |
|
1 × DVI-I | |
|
1 × HDMI | |
|
Audio |
1 × PC-Audio |
|
Touch Connector |
1 × USB |
|
Power Connector |
1 × DC2.0 |
|
| |
|
Operating Temperature Range |
-10~60°C (-20~70°C Optional) |
|
Humidity Range (RH) |
10-90% |
|
24/7/365 Use |
Supported |
|
| |
|
Power Indicator |
Green LED |
|
Power Input |
DC 12V |
|
Power Consumption |
8.75W |
|
| |
|
11.6”Chassis LCD Monitor with Resistive Touch |
ITD11CMT101 |
|
11.6”Chassis LCD Monitor with IR Touch |
ITD11CMT201 |
|
11.6”Chassis LCD Monitor with SAW Touch |
ITD11CMT301 |
|
11.6”Chassis LCD Monitor with PCAP Touch |
ITD11CMT501 |
|
11.6”Chassis LCD Monitor with Tempered Glass |
ITD11CMG101 |
