Full IP65/IP66 High Brightness Touchscreen Monitor

Model Name

ITD18CMG1IPHBA1

IP Rating

Full IP65/IP66(IP67 optional)

LCD Panel

Screen Diagonal (Inch/cm)

18.5”

Display Active Screen Size (mm)

409.8(H) ×230.4(V)

Aspect Ratio

4:3

Physical Resolution

1366×768

Maximum Resolution Supported

1920×1080

Colors

16.7M

Brightness (cd/m2)

1000 cd/m2

Contrast Ratio

1000:1

View Angels

85/85/80/80

Backlight/Backlight Lifetime

LED Backlight with 50000 Hours’ Lifetime

Touch Panel

Touch Options

Resistive, PCAP

Touch Drivers

Windows, Linux, Android, Mac, Raspberry Pi

Input / Output

Video Input

1 × VGA

N/A

1 × HDMI(Optional)

Audio

N/A

Touch Connector

1 × USB(Optional)

Power Connector

1 × DC2.0

Operation

Operating Temperature Range

-10~60°C (-20~70°C Optional)

Humidity Range (RH)

10-90%

24/7/365 Use

Supported

Power

Power Indicator

N/A

Power Input

DC 12V

Power Consumption

38W

Order Information

18.5”1000nits Full IP65/IP66 LCD Monitor with Resistive Touch, Aluminum Housing

ITD18CMT1IPHBA1

18.5”1000nits Full IP65/IP66 LCD Monitor with PCAP Touch, Aluminum Housing

ITD18CMT5IPHBA1

18.5”1000nits Full IP65/IP66 LCD Monitor with Resistive Touch, Stainless Steel housing

ITD18CMT1IPHBS1

18.5”1000nits Full IP65/IP66 LCD Monitor with PCAP Touch, Stainless Steel Housing

ITD18CMT5IPHBS1

18.5”1000nits Full IP65/IP66 LCD Monitor with Tempered Glass, Aluminum Housing

ITD18CMG1IPHBA1

18.5”1000nits Full IP65/IP66 LCD Monitor with Tempered Glass, Stainless Steel housing housing

ITD18CMG1IPHBS1
