FEATURES
- 27-inch high-performance TFT LCD panel with 1920 ¡Á 1080 (Full HD) resolution, providing an expansive viewing area and sharper visuals for complex HMIs, industrial dashboards, and machine control systems
- Seamless flush front panel with reinforced support, engineered to minimize dust and grime accumulation while allowing rapid, easy cleaning in heavy-duty industrial environments
- Robust steel and aluminum construction, combining a durable steel body with a reinforced aluminum bezel, designed to resist vibration, mechanical shock, and continuous operation in harsh factory or outdoor settings
- Front IP65-rated protection, safeguarding against dust, water splashes, oils, and other industrial contaminants, ensuring reliable performance in challenging environments
- Designed for 24/7 industrial operation, incorporating heat-resistant components and high-grade electronics to maintain stability and reliability in mission-critical monitoring and automation systems
- Touchscreen options available, including resistive single-touch for glove-friendly operation and PCAP multi-touch for intuitive control and modern operator interfaces
- Wide DC voltage support, accepting 12V DC standard input or 9¨C36V DC flexible range, suitable for both stationary and mobile/vehicle-mounted industrial setups
- Versatile installation capabilities, supporting panel embedding, VESA mounting, wall installation, and desktop placement, allowing seamless integration into new or existing systems
- Long-term product lifecycle and supply assurance, minimizing maintenance costs, reducing redesign risk, and ensuring consistent performance across multi-year industrial projects
Panel Mount Touch Screen Monitor | |
| Model Name | ITD27PMT5X1_V2 |
| IP Rating | IP65 Front Panel |
LCD Panel | |
| Screen Diagonal (Inch) | 27¡± |
| Display Active Screen Size (mm) | 597.888(W)¡Á336.312(H) |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920¡Á1080 |
| Pixel Pitch(mm) | 0.3114¡Á0.3114 |
| Colors | 16.7M |
| Response Time | 14ms |
| Brightness (cd/m2) | 300 (500~1500 optional) |
| Contrast Ratio | 1000:1 |
| View Angels | 89/89/89/89 |
| Backlight/Backlight Lifetime | LED Backlight with 50000Hours'Lifetime |
Touch Panel | |
| Touch Options | PCAP |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
Input / Output | |
| Video Input | 1 ¡Á VGA |
| 1 ¡Á DVI-I, 1 ¡Á Display Port(optional) | |
| 1 ¡Á HDMI | |
| Audio | 1 ¡Á PC-Audio |
| Touch Connector | 1 ¡Á USB |
| Power Connector | 1 ¡Á Phoenix Connector |
Operation | |
| Operating Temperature Range | -10~60¡ãC (-20~70¡ãC Optional) |
| Humidity Range (RH) | 10-90% |
| 24/7/365 Use | Supported |
Power | |
| Power Indicator | Green LED |
| Power Input | DC9~28V input |
| Power Consumption | 26W |
Order Information | |
| 27¡±Panel Mount LCD Monitor with PCAP Touch | ITD27PMT5X1_V2 |
| 27¡±Panel Mount LCD Monitor with Tempered Glass | ITD27PMG1X1_V2 |
| 27¡±1000nits Panel Mount LCD Monitor with PCAP Touch | ITD27PMT5HBX2_V2 |
| 27¡±1000nits Panel Mount LCD Monitor with Tempered Glass | ITD27PMG1HBX2_V2 |
| 27¡±1500nits Panel Mount LCD Monitor with PCAP Touch | ITD27PMT5HBX1_V2 |
| 27¡±1500nits Panel Mount LCD Monitor with Tempered Glass | ITD27PMG1HBX1_V2 |
