Model Name |
ITD49CMAIPL**** | ||
IP Rating |
IP65 | ||
| |||
1 ¡ÁUSB 2.0, 1¡ÁSD Card Slot, 1¡ÁHDMI Input Video Formats Supported: MP4, AVI, DAT, MPG, RM, RMVB, AVC, FLV Audio Formats Supported: MP3, WMA, OGG, AAC, AC, DTS, FLAC, APE Picture Formats Supported: JPEG, BMP, GIF, PNG File Formats Supported: FAT, FAT32, NTFS | |||
| |||
ARM Android Based RK3288(RK3368 optional) |
X86 Windows Based |
X86 Windows Based | |
CPU: Quad-Core Cortex-A17 1.8GHz |
CPU: Intel Celeron J1900 |
CPU: Intel Core i3/i5/i7 | |
Chipset: N/A |
Chipset: Intel NM10 Express |
Chipset: Intel HD Graphics, Support 1080p | |
Memory: 1G/2G |
Memory: 2GB(Max. 8GB) |
Memory: 2GB(Max. 8GB) | |
HDD/SSD: 8G |
HDD/SSD:500G/64G |
HDD/SSD:500G/64G | |
1¡ÁHDMI |
1¡ÁVGA, 1¡ÁHDMI |
1¡ÁVGA, 1¡ÁHDMI | |
1¡ÁUSB 2.0 |
2¡ÁUSB 2.0, 2¡ÁUSB3.0 |
2¡ÁUSB 2.0, 2¡ÁUSB3.0 | |
1¡Ámini-SD slot |
1¡ÁCOM(RS232/422/485) |
1¡ÁCOM(RS232/422/485) | |
1¡ÁLAN |
1¡ÁLAN |
1¡ÁLAN | |
1¡ÁAudio Out |
1¡ÁAudio Out, 1¡ÁMIC In |
1¡ÁAudio Out, 1¡ÁMIC In | |
Expansion: SSD |
Expansion: USB, COM, Mini-PCIe |
Expansion: USB, COM, Mini-PCIe | |
| |||
Screen Diagonal (Inch) |
49¡± | ||
Display Active Screen Size (cm) |
1073.8(H)¡Á604(V) | ||
Aspect Ratio |
16:9 | ||
Physical Resolution |
1920¡Á1080 | ||
Maximum Resolution Supported |
1920¡Á1080 | ||
Colors |
16.7M | ||
Brightness (cd/m2) |
1500 cd/m2 | ||
Contrast Ratio |
1300:1 | ||
View Angels |
89/89/89/89 | ||
Backlight/Backlight Lifetime |
LED Backlight with 50000Hours'Lifetime | ||
| |||
Operating Temperature |
-20~55¡ãC(Fan-Cooling); -40~55¡ãC (Air Condition Built-in) | ||
|
10-90% | ||
24/7/365 Use |
Supported | ||
| |||
Touch Options |
IR, PCAP, Touch Foil | ||
Touch Drivers |
Windows, Linux, Android, Mac, Raspberry Pi | ||
| |||
Power Indicator |
Green LED | ||
Power Input |
Internal Power Supply, AC 100V~240V | ||
Power Consumption Speakers |
240W 2¡Á5W | ||
| |||
49¡±Outdoor Free Standing Single DS with Aircon, AG Glass |
ITD49CMAIPLG3A1 | ||
49¡±Outdoor Free Standing Single DS with Fan-Cooling, AG Glass |
ITD49CMFIPLG3A1 | ||
49¡±Outdoor Free Standing Android DS with Aircon, AG Glass |
ITD49CMAIPLG3E1 | ||
49¡±Outdoor Free Standing Android DS with Fan-Cooling, AG Glass |
ITD49CMFIPLG3E1 | ||
49¡±Outdoor Free Standing Windows J1900 DS wit,h Ai,,rcon,, AG Glass |
ITD49CMAIPLG3J1 | ||
49¡±Outdoor Free Standing Windows J1900 DS with Fan-Cooling, AG Glass |
ITD49CMFIPLG3J1 | ||
49¡±Outdoor Free Standing Windows i3 DS with Aircon, AG Glass |
ITD49CMAIPLG3I3 | ||
49¡±Outdoor Free Standing Windows i3 DS with Fan-Cooling, AG Glass |
ITD49CMFIPLG3I3 | ||
49¡±Outdoor Free Standing Android DS with Aircon, Touch Foil |
ITD49CMAIPLT7E1 | ||
49¡±Outdoor Free Standing Android DS with Fan-Cooling, Touch Foil |
ITD49CMFIPLT7E1 | ||
49¡±Outdoor Free Standing Windows J1900 DS with Aircon, Touch Foil |
ITD49CMAIPLT7J1 | ||
49¡±Outdoor Free Standing Windows J1900 DS with Fan-Cooling, Touch Foil |
ITD49CMFIPLT7J1 | ||
49¡±Outdoor Free Standing Windows i3 DS with Aircon, Touch Foil |
ITD49CMAIPLT7I3 | ||
49¡±Outdoor Free Standing Windows i3 DS with Fan-Cooling, Touch Foil |
ITD49CMFIPLT7I3 |
