7 inch Touch Panel Computerwith ID Card Reader/Books Induction
BENEFITES
-Exceptional quality and highly engineered industrial panel computer
-High Performance Processor, Graphics, Memory and Power
-Edge to edge design with true flat surface, easy to clean
-Equipped with projected capacitive touch screen
-All steel construction designed for harsh and industrial environments
-Easy-to-install embedded/panel mounting with clamps
-Robust design with aluminum NEMA 4/ IP65 front panel
-Flexible, reliable, and ruggedized for open platform HMI/SCADA
-Integrated with RFID reader, finger-reader, camera, microphone, etc. peripherals
-Long lasting product cycle for continuity thru all phases of project

OVERVIEW
ITD industrial touch panel computer PCs provide reliability, durability, and industrial OEMs with vast selection of technologies and solutions simplify PLC, HMI, and SCADA applications. The rugged all steel enclosures with robust aluminum alloy front bezel with thickness of 3mm, 6mm, 10mm optional and highly-durable glass front surface provide the durability needed for demanding industrial environments. The flat industrial panel PC is combined with PCAP or resistive touch makes true flat surface with easy to clean. The custom industrial panel PCs come with industrial/commercial-grade LCD flat screen sizes, touchscreen interface, x86 based or ARM based comprehensive embedded processors and chipsets, integrated RFID/NFC/MSR smart card readers, web camera (face recognition), QR reader, finger reader, thermal printer, barcode scanner, etc. peripherals, low power consumption, fanless design, and scratch-resistant capabilities are ideal for process manufacturing, discrete manufacturing, industrial automation, process control, building automation, access control, smart intercom, room reservation, room scheduling, and custom HMI applications.

7 inch Touch Panel Computer with ID Card Reader/Books Induction

Model Name

ITD07PPCT5X*****

IP Rating

IP65 Front Panel



PC Systems Options



ARM Android Based RK3288(RK3368/3399 optional)

X86 Windows Based

X86 Windows Based

CPU: Quad-Core Cortex-A17 1.8GHz

CPU: Intel Celeron J1900

CPU: Intel Core i3/i5/i7

Chipset: N/A

Chipset: Intel HD Graphics, Support 1080p

Chipset: Intel HD Graphics, Support 1080p

Memory: 1G/2G

Memory: 2GB(Max. 8GB)

Memory: 2GB(Max. 8GB)

HDD/SSD: 8G

HDD/SSD:500G/64G

HDD/SSD:500G/64G

1¡ÁHDMI

1¡ÁVGA, 1¡ÁHDMI

1¡ÁVGA, 1¡ÁHDMI

1¡ÁUSB 2.0

2¡ÁUSB 2.0, 2¡ÁUSB3.0

2¡ÁUSB 2.0, 2¡ÁUSB3.0

1¡Ámini-SD slot

1¡ÁCOM(RS232/422/485)

1¡ÁCOM(RS232/422/485)

1¡ÁLAN

1¡ÁLAN

1¡ÁLAN

1¡ÁAudio Out

1¡ÁAudio Out, 1¡ÁMIC In

1¡ÁAudio Out, 1¡ÁMIC In

Expansion: SSD

Expansion: USB, COM, Mini-PCIe

Expansion: USB, COM, Mini-PCIe



LCD Panel



Screen Diagonal (Inch)

7¡±

Display Active Screen Size (cm)

154.214(H)¡Á85.92(V)

Aspect Ratio

16:9

Physical Resolution

1024¡Á600

Maximum Resolution Supported

1920¡Á1080

Colors

262K/16.7M

Brightness (cd/m2)

400

Contrast Ratio

800:1

View Angels

75/75/70/75

Backlight/Backlight Lifetime

LED Backlight with 50000Hours'Lifetime



Touch Panel



Touch Options

PCAP

Touch Drivers

Windows, Linux, Android, Mac, Raspberry Pi



Operation



Operating Temperature Range

-10~60¡ãC (-20~70¡ãC Optional)

Humidity Range (RH)

10-90%

24/7/365 Use

Supported



Power



Power Indicator

Green LED

Power Input

DC 12V

Power Consumption

15W



Order Information



7¡±Custom PCAP Touch Android PC RK3288 with ID Card Reader&Books Induction

ITD07PPCT5XE1-ICR-BI

7¡±Custom PCAP Touch Android PC RK3399 with ID Card Reader&Books Induction

ITD07PPCT5XE1-ICR-BI

7¡±Custom PCAP Touch PC Intel J1900 with ID Card Reader&Books Induction

ITD07PPCT5XJ1-ICR-BI

7¡±Custom PCAP Touch PC Intel i3 with ID Card Reader&Books Induction

ITD07PPCT5XI3-ICR-BI

7¡±Custom PCAP Touch PC Intel i5 with ID Card Reader&Books Induction

ITD07PPCT5XI5-ICR-BI

7¡±Custom PCAP Touch PC Intel i7 with ID Card Reader&Books Induction

ITD07PPCT5XI7-ICR-BI
