OVERVIEW
ITD¡¯s line of projected capacitive touch displays are engineered specifically for industrial/commercial customers who are looking for a rugged and durable touch screen without having to sacrifice on image quality. Featuring an edge to edge zero bezel design, the touchscreen monitor can easily be wiped clean, thereby eliminating having to worry about dust and dirt collection, which helps extend the use of your display. The PCAP touchscreen LCD monitors can not only used alone as VESA wall mounted or on table with desktop stand, but also can come with side mounting brackets as open frame rear mounted in cabinets. ITD industrial multi touch displays are accurate, responsive and easy-to-use, enabling migration of existing single touch applications to a gesture-based interface that creates and delivers popular user interactions such as pan, zoom and rotate, which ideal for retail, kiosks and interactive digital signage.
|
| |
|
Model Name |
ITD12OFT5K1 |
|
IP Rating |
IP65 Front Panel |
|
| |
|
Screen Diagonal (Inch/cm) |
12.1¡± |
|
Display Active Screen Size (mm) |
245.76(H)¡Á184.32(V) |
|
Aspect Ratio |
4:3 |
|
Physical Resolution |
1024¡Á768 |
|
Maximum Resolution Supported |
1920¡Á1080 |
|
Colors |
262K/16.2M |
|
Brightness (cd/m2) |
500 |
|
Contrast Ratio |
700:1 |
|
View Angels |
80/80/80/80 |
|
Backlight/Backlight Lifetime |
LED Backlight with 50000Hours'Lifetime |
|
| |
|
Touch Technology |
Projected Capacitive Touch |
|
Touch Drivers |
Windows, Linux, Android, Mac, Raspberry Pi |
|
Touch Life |
50,000,000times/click |
|
Surface Hardness |
7H |
|
| |
|
Video Input |
1 ¡Á VGA |
|
1 ¡Á HDMI | |
|
Audio |
1 ¡Á PC-Audio |
|
Touch Connector |
1 ¡Á USB |
|
Power Connector |
1 ¡Á DC2.0 |
|
| |
|
Operating Temperature Range |
-10~60¡ãC (-20~70¡ãC Optional) |
|
Humidity Range (RH) |
10-90% |
|
24/7/365 Use |
Supported |
|
| |
|
Power Indicator |
Green LED |
|
Power Input |
DC 12V |
|
Power Consumption |
20W |
|
| |
|
Side Mounting Brackets, Desktop Stand, VESA Mounting Brackets, Webcam | |
|
| |
|
12.1¡±Non Touch Monitor with Tempered Glass |
ITD12OFG1K1 |
