OVERVIEW
ITD Zero-Bezel PCAP touch panel PCs come with built-in card readers like NFC, RFID and IC card. The fanless design decreases downtime and reduces the need for on-site support due to cooling system failure. The multi-touch display allows for configuration and notifications while RFID/NFC reader and camera act as the access control method. The system meets MIL-STD 810F testing procedures and the IP65 compliant front panel is sealed against water and dust intrusion. The built-in RFID/NFC reader works with EM and MIFARE cards and tags. The intuitive touch panel allows for easy operation and the built-in webcam can be used as an intercom through the LAN connection or as a biometric access control system based on facial and voice recognition. The integrated card reader makes the series a complete access control and security system for commercial, residential, industrial, financial, and educational and government institutions.
|
| |||
|
Model Name |
ITD43PPCT5K**-RFID/NFC | ||
|
IP Rating |
IP65 Front Panel | ||
|
| |||
|
ARM Android Based RK3288(RK3368 optional) |
X86 Windows Based |
X86 Windows Based | |
|
CPU: Quad-Core Cortex-A17 1.8GHz |
CPU: Intel Celeron J1900 |
CPU: Intel Core i3/i5/i7 | |
|
Chipset: N/A |
Chipset: Intel HD Graphics, Support 1080p |
Chipset: Intel HD Graphics, Support 1080p | |
|
Memory: 1G/2G |
Memory: 2GB(Max. 8GB) |
Memory: 2GB(Max. 8GB) | |
|
HDD/SSD: 8G |
HDD/SSD:500G/64G |
HDD/SSD:500G/64G | |
|
1×HDMI |
1×VGA, 1×HDMI |
1×VGA, 1×HDMI | |
|
1×USB 2.0 |
2×USB 2.0, 2×USB3.0 |
2×USB 2.0, 2×USB3.0 | |
|
1×mini-SD slot |
1×COM(RS232/422/485) |
1×COM(RS232/422/485) | |
|
1×LAN |
1×LAN |
1×LAN | |
|
1×Audio Out |
1×Audio Out, 1×MIC In |
1×Audio Out, 1×MIC In | |
|
Expansion: SSD |
Expansion: USB, COM, Mini-PCIe |
Expansion: USB, COM, Mini-PCIe | |
|
| |||
|
Screen Diagonal (Inch/cm) |
43” | ||
|
Display Active Screen Size (mm) |
930.24(H) ×523.26(V) | ||
|
Aspect Ratio |
16:9 | ||
|
Physical Resolution |
1920×1080 | ||
|
Maximum Resolution Supported |
1920×1080 | ||
|
Colors |
16.7M | ||
|
Brightness (cd/m2) |
400nits | ||
|
Contrast Ratio |
1200:1 | ||
|
View Angels |
89/89/89/89 | ||
|
Backlight/Backlight Lifetime |
LED Backlight with 50000 Hours’ Lifetime | ||
|
| |||
|
Touch Technology |
Projected Capacitive Touch | ||
|
Touch Drivers |
Windows, Linux, Android, Mac, Raspberry Pi | ||
|
Touch Life |
50,000,000 Times/Click | ||
|
Surface Hardness |
7H | ||
|
OS Support |
Windows, Linux, Android, Mac, Raspberry Pi | ||
|
| |||
|
Operating Temperature Range |
-10~60°C (-20~70°C Optional) | ||
|
Humidity Range (RH) |
10-90% | ||
|
24/7/365 Use |
Supported | ||
|
| |||
|
Power Indicator |
Green LED | ||
|
Power Input |
AC100-240V | ||
|
Power Consumption |
78W | ||
|
| |||
|
43”PCAP Touch Panel PC with J1900, RFID |
ITD43PPCT5KJ1-RFID | ||
|
43” PCAP Touch Panel PC with Android RK3368, RFID 43”PCAP Touch Panel PC with Android RK3399, RFID |
ITD43PPCT5KE1-RFID ITD43PPCT5KE2-RFID | ||
|
43”PCAP Touch Panel PC with i3, RFID |
ITD43PPCT5KI3-RFID | ||
|
43” PCAP Touch Panel PC with i5, RFID 43”PCAP Touch Panel PC with i7, RFID |
ITD43PPCT5KI5-RFID ITD43PPCT5KI7-RFID | ||
|
43”PCAP Touch Panel PC with J1900, NFC |
ITD43PPCT5KJ1-NFC | ||
|
43” PCAP Touch Panel PC with Android RK3368, NFC 43”PCAP Touch Panel PC with Android RK3399, NFC |
ITD43PPCT5KE1-NFC ITD43PPCT5KE2-NFC | ||
|
43”PCAP Touch Panel PC with i3, NFC |
ITD43PPCT5KI3-NFC | ||
|
43” PCAP Touch Panel PC with i5, NFC 43”PCAP Touch Panel PC with i7, NFC |
ITD43PPCT5KI5-NFC ITD43PPCT5KI7-NFC | ||
43” PCAP Touch Panel PC with Android RK3368, NFC
43”PCAP Touch Panel PC with Android RK3399, NFC
ITD43PPCT5KE1-NFC
ITD43PPCT5KE2-NFC
43”PCAP Touch Panel PC with i3, NFC
ITD43PPCT5KI3-NFC
43” PCAP Touch Panel PC with i5, NFC
43”PCAP Touch Panel PC with i7, NFC
ITD43PPCT5KI5-NFC
ITD43PPCT5KI7-NFC
