BENEFITES
-IoT gateway ready for future requirements
-Energy-efficient and fan-less IPC Systems
-Intel Bay Trail-M J1900 Quad-Core 2.0GHz
-Maintenance-free with no rotating disk (HDD)
-Robust aluminum die-casting housing
-Power-optimized PC with 32- or 64-bit OS
-High system availability and data security
-High data transfer rates and redundancy
|
| |
|
Model Name |
ITD-MNPC-J1900 |
|
IP Rating |
N/A |
|
| |
|
CPU |
Intel Bay Trail-M J1900 Quad-Core 2.0GHz |
|
Chipset |
Intel HD Graphics |
|
Graphics |
Intel HD Graphics |
|
Audio |
MIC-IN, LINE-OUT |
|
Memory |
2GB, up to Max. 8GB |
|
Storage |
320GB SATA up Max. 1TB; 32GB SSD up to Max. 512GB (MSATA Supported) |
|
Driver Support |
Windows CE/XP/7/8/10, Linux, |
|
|
|
|
Serial Ports |
1 x COM |
|
USB Ports |
2 x USB2.0, 2 X USB3.0 |
|
|
1 x HDMI |
|
|
1 x VGA |
|
Mini PCIe |
1 x Mini PCIe |
|
Audio |
MIC-IN, LINE-OUT |
|
Communication (3G/4G, WIFI) |
Optional |
|
LAN |
2 x 10/100/1000Mbps Ethernet |
|
Power Port |
1 x DC 12V Input (1 x ON/OFF Power Switch) |
|
| |
|
Power Indicator |
Green LED |
|
Power Input |
DC 12V |
|
Power Consumption |
TBA |
|
| |
|
Operating Temperature |
-10~60¡æ |
|
Humidity Range |
20%~90% (Non Condensing) |
|
Housing Material |
Aluminum Die-Casting |
|
Housing Dimension (L ¡Á W ¡Á H) |
134mm x 124mm x 36mm |
